Drive 15005L - Bed Rail Installation; Rail Installation Guide

7
Bed Rail Installation
The Deck Frame contains labels that provide the location for installing Half Rails and Full Rails.
• On the Head Section and Foot Sections, a Label will indicate the notch location for alignment of the Full
Rail Cross Brace that must be positioned in between the two black springs. A second Label will indicate
alignment for the Half Rail clamp to be positioned with the Black Spring centered between the clamp.
Half Rails Full Rails
