Drive 15560 - Motor Installation Method B

10
REV4.3.5.14
Assembly Instructions Cont.
B4.Removethecoversfromthemotorandplaceunderthebedandalignedwiththeactuatorunderthehead
section. There are labels on the motor that provide direction and placement in relation to the head section.
B5.Withbothhands,liftthemotorandinsertintotheactuatorandframeasshown.Withthepalmofyour
handsnapthemotorushtoactuatorbar.
B3. Priortoinstallation,makesurethatthe2whitemotorblocksareintheretractedposition.
CORRECT INCORRECT
