Drive 15560 - Page 16

16
REV4.3.5.14
Assembly Instructions Cont.
18. Insert the bed rail into the receptacle. Repeat for the other rail.
19. Toinstallhalfrails,locatethelabellocatedontheheadsectionoftheframe.Thehalfrailclampshould
 beinstalledoverthislabel.Alignxedclampjawinfrontofbedframerailasshownbelow.Align
 movableclampjawontopofbedframerail,andturnknobclockwiseuntilclampistight,securingsafety
rail to bed frame rail.
CORRECT
Wheninstallingbedrail,onlyplaceone
(1)railonbedperside.
INCORRECT
DO NOT place 2 bed rails on the same side
ofthebedasshownabove.
WARNING-INCORRECTMOUNTINGMAYCAUSEINJURYORDEATH
