Drive 15560 - Motor Installation Method A

6
REV4.3.5.14
Assembly Instructions Cont.
A2. Align the opening on the head end of the
 motorwiththeangeontheheadsectionof
 thebedandinserttheangeintothemotor
compartment.
Actuator Bar
Flange
A3. Withthepalmofyourhand,snapthemotor
 ushtotheactuatorbar.
A4. Align the opening on the foot end of the
 motorwiththeangeonthefootsectionof
 thebedandinserttheangeintothemotor
compartment.
Method A
Installation of the motor when bed frame is on its side
A1. Priortoinstallation,makesurethatthe2whitemotorblocksareintheretractedposition.
CORRECT INCORRECT
A5. Withthepalmofyourhand,snapthemotor
 ushtotheactuatorbar.
