DROPSA VIP5 Pro - Page 11

11/27
For further details also check the completed electrical diagram enclosure with your specific equipment.
NOTE: To connect micro-switches or clean contacts inputs, equipped by creating a terminals for the
positive power supply (+) and the relative input P (IN +), you must make a link between (+) and (IN+) after
that connect the 2 wires of micro-switch at (-) or (IN-)
Fig. 4
