Drucker Diagnostics QBC STAR - Tube Error Codes

QBC STAR System Operator’s Manual
6000-300-000 7–16
Error Number Description Corrective Action
1 Low ll volume
1. Record the error message on the LCD display
2. Create a support le (Ref. page 2-8)
3. Prepare a new tube (Ref. pages 4-2 through 4-5)
4. Insert the tube into the instrument, close the door and press
the “STAR” button
2 High ll volume
1. Record the error message on the LCD display
2. Create a support le (Ref. page 2-8)
3. Prepare a new tube (Ref. pages 4-2 through 4-5)
4. Insert the tube into the instrument, close the door and press
the “STAR” button
3 Bad oat length
1. Record the error message on the LCD display
2. Create a support le (Ref. page 2-8)
3. If the lid is not open, depress the door release latch located
on the front of the instrument.
4. Rotate the tube 180 degrees and reinsert it in the rotor
5. Close the lid and rerun the tube (Ref. page 4-7)
6. If the problem persists, prepare a new tube, insert it into the
instrument, close the lid and press the “STAR” button
7. If the problem persists after rerunning a new tube, create a
new support le and contact Technical Support
4 Bad oat signature
1. Record the error message on the LCD display
2. Create a support le (Ref. page 2-8)
3. Open the lid, rotate the sample 180 degrees and reinsert it
into the rotor
4. Close the lid and rescan the sample
5. If the problem persists, draw a new sample and retest
6. If the problem persists after rerunning a new tube, create a
new support le and contact Technical Support
6 Unreadable buffy coat
1. Record the error message on the LCD display
2. Create a support le (Ref. page 2-8)
3. Open the lid, rotate the sample 180 degrees and reinsert it
into rotor
4. Close lid and rescan the sample
5. If the problem persists, draw a new sample and retest
6. If the problem persists after retest, create a new support le
and contact Technical Support
7 Float not descended
1. Record the error message on the LCD display
2. Create a support le (Ref. page 2-8)
3. Open the lid and visually check the sample
a. If the oat did not descend or no visible buffy layer is
observed, draw a new sample and retest
b. If the oat is descended or a visible buffy layer is observed,
rotate the sample 180 degrees and rescan the sample
4. If the problem persists, create a new support le and contact
Technical Support
If any of the following tube error messages appear on the printer results report and LCD display, fill and
run a new tube.
Tube Error Codes
