4.3 Changing The Filter Element
The life expectancy of the lter element is approximately 9 months. Gardner
Denver Drum recommends that the lter condition is checked on a regular
basis.
The cooler is tted with a lter condition gauge (6) which is located at the
front of the outer cover of the Hydrapak. When the needle of the gauge has
reached the ‘Red’ section of the gauge the lter element will need changing.
1. Unscrew Filler Cap (1) and remove, then unscrew and remove lter
retaining nut (2).
2. Remove Strainer Disc (3) from the sealing ring and remove the
spring (4) located on top of the lter element .
3. Withdraw the lter element (5) from the Hydrapak reservoir. The
lter is a non-serviceable item and must be replaced at the end of its
service life.
Re-tting a new Filter Element is a reversal of the above.
Maintenance
Spring tension is released
during this operation.
CAUTION
6
1
2
3
4
5
Fig. 10 Changing the Filter Element
When re-tting the Filler Cap,
do not use excessive force.
Hand Tight only to avoid
distortion of the tank.
CAUTION
When replacing the new lter
element, ensure it is located
into the housing at the bottom
of the tank.
NOTE
Key
1. Filler Cap
2. Retaining Nut
3. Strainer Disc
4. Spring
5. Filter Element
6. Filter Condition Gauge
Take care not to drop any
components or contamination
into the tank.
CAUTION
Page 16
