2. Click the Network Detection tab to enter the Network Detection interface.
3. Select the backup device from the dropdown list of Device Name, as shown in Figure 9. 24.
Click Refresh button if the connected local backup device cannot be displayed. When it fails to detect
the backup device, please check whether it is compatible with the NVR. You can format the backup
device if the format is incorrect.
Figure 9. 24 Export Network Packet
4. Click Export button to start exporting.
Up to 1M data can be exported each time.
9.4.3 Checking the Network Status
Purpose:
You can also check the network status and quick set the network parameters in this interface.
Steps:
Click the Status button on the lower- right corner of the page.
Figure 9. 25 Network Status Checking
If the network is normal the following message box pops out.
