3.1 Introduction of Live View
Live view shows you the video image getting from each camera in real time. The NVR automatically enters Live
View mode when powered on. It is also at the very top of the menu hierarchy, thus pressing the ESC many times
(depending on which menu you’re on) brings you to the Live View mode.
Live View Icons
In the live view mode, there are icons at the upper-right of the screen for each channel, showing the status of the
record and alarm in the channel, so that you can know whether the channel is recorded, or whether there are alarms
occur as soon as possible.
Table 3. 1 Description of Live View Icons
Alarm (video loss, video tampering, motion detection, sensor alarm or VCA alarm)
Event/Exception (motion detection, sensor alarm, or exception information, appears at
the lower-left corner of the screen. Please refer to Chapter 8.7 Setting Alarm Response
Actions for details.)
