DSC PC1565 - VERSION 2.3 User Manual

Programming Worksheets
41
[390] LINKS Preamble (First Telephone Number) (Section 5.26 “LINKS1000 Cellular Communicator” on page 26)
Default: FFFF I_______I_______I_______I_______I (Program all unused digits with Hex F)
[391] LINKS Preamble (Second Telephone Number)
(Section 5.26 “LINKS1000 Cellular Communicator” on page 26)
Default: FFFF I_______I_______I_______I_______I (Program all unused digits with Hex F)
[392] LINKS Preamble (Third Telephone Number)
(Section 5.26 “LINKS1000 Cellular Communicator” on page 26)
Default: FFFF I_______I_______I_______I_______I (Program all unused digits with Hex F)
[393] LINKS Special Function Preamble (All Telephone Numbers)
(Section 5.26 “LINKS1000 Cellular Communicator” on
page 26)
Default: FFFFFF I_______I_______I_______I_______I_______I_______I (Program all unused digits with Hex F)
•Enter [*][2][*] (HEX B) to dial [*] • Enter [*][3][*] (HEX C) to dial [#]
Downloading Options
[401] First Downloading Option Code (Section 5.10 “Downloading” on page 20)
Default Option ON Off
OFF I_______I 1 Answering machine/double call enabledAnswering machine/double call disabled
ON I_______I 2 User Can Enable DLS Window User Cannot Enable DLS Window
OFF
I_______I 3 Call-Back Enabled Call-Back Disabled
OFF I_______I 4 User-initiated call-up enabled User-initiated call-up disabled
OFF I_______I 5-8 For future use
[402] Downloading Computer’s Telephone Number (32 Digits)
(Section 5.10 “Downloading” on page 20)
I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I
[403] Downloading Access Code (Section 5.10 “Downloading” on page 20)
Default: 1555 I_______I_______I_______I_______I Enter 4 HEX digits
[404] Panel Identification Code
(Section 5.10 “Downloading” on page 20)
Default: 1555 I_______I_______I_______I_______I Enter 4 HEX digits
[405] Answering Machine Double-call Timer
(Section 5.10 “Downloading” on page 20)
Default: 060 I_______I_______I_______I (Valid entries are 001-255 seconds)
[406] Number of Rings to Answer On
(Section 5.10 “Downloading” on page 20)
Default: 000 I_______I_______I_______I (Valid entries are 000-255 rings)
[490] LINKS Preamble (Downloading Telephone Number)
(Section 5.10 “Downloading” on page 20)
Default: FFFF I_______I_______I_______I_______I (Program all unused digits with Hex F)
[499] [Installer’s Code] [499] Initiate PC-Link (Local Downloading)
(Section 5.10 “Downloading” on page 20)
International Programming
[700] Clock Adjust (Section 5.28 “Clock Adjust” on page 26)
Default: 60 I_______I_______I (Valid entries are 01-99 seconds)
[701] First International Options Code
Default Option ON Off Section Page #
OFF
I_______I 1 50 Hz AC 60 Hz AC 2.2 3
OFF I_______I 2 Time Base is Internal Crystal Time Base is AC Line 5.29 27
OFF
I_______I 3 AC/DC Arming Inhibit enabled AC/DC Arming Inhibit disabled 5.17 24
OFF I_______I 4 All System Tampers Require Installer Reset All System Tampers follow Restore 5.25 25
OFF I_______I 5 6-Digit User Access Codes 4-Digit User Access Codes 5.1 15
OFF
I_______I 6 Busy tone detection enabled Busy tone detection disabled 5.5 17
OFF I_______I 7 High Current Battery Charge Standard Current Battery Charge 2.2 3
OFF I_______I 8 For future use

DSC PC1565 - VERSION 2.3 Specifications

General

Partitions	2
Event Buffer	128 events
Communicator	Built-in
PGM Outputs	2 (expandable)
Alarm System Type	Wired
Battery Backup	12VDC, 4Ah
Keypads Supported	8
Communication	Phone line
Power Supply	16.5VAC, 40VA
Operating Temperature	0°C to 49°C (32°F to 120°F)
