33
PC3000 Version 7.7
[28] Programmable Input and Output Options
Page 20
Default
2
Auxiliary Input Zone Enter 1, 2, 3 or 4 for options below 1, 2, 3 and 4 are
(Normally open, momentary [0] Not used the only valid entries
closure to “Aux +”) [1] Silent 24 hour input
[2] Audible 24 hour input
[3] Momentary key arming
[4] Forced answer
2 Programmable Output Enter 0 to F for options below 0 through F are
(A 50 mA switch to ground.) [0] LINKS support output the only valid entries
Note: A relay must be used to
[1] Ground start pulse
obtain more current.
[2] Utility output no access code
[3] Utility output any access code
[4] Utility output Group A access code
[5] Utility output Group B access code
[6] Keypad buzzer follow mode
[7] System status (arm/disarm) output
[8] Strobe output (latched alarm output)
[9] Failure to communicate output
[A] TLM and alarm
[B] Courtesy pulse
[C]PGM squawk output
[D]2nd line slave
[E] Kissoff output
[F] Remote operation
(DLS-1 version 5.3 or later)
Note: Section [29]...[33] are used for split arming or split reporting only.
[29] Zone Group A Assignment
Page 21
Default
On Zone Light 1
On
Zone Light 2
On Zone Light 3
On
Zone Light 4
On Zone Light 5
On
Zone Light 6
On Zone Light 7
On Zone Light 8
[30] Zone Group B Assignment
Page 21
Default
On Zone Light 1
On
Zone Light 2
On Zone Light 3
On
Zone Light 4
On Zone Light 5
On Zone Light 6
On
Zone Light 7
On Zone Light 8
Note:
If zone light is on that zone is assigned to
Group B.
If light is on in both sections, the zone is common to both
sides and will only be armed if both sides are armed.
Note:
If zone light is on that zone is assigned to
Group A.
Zones 9 to 16 are permanently assigned to Group A.
