Changes for PC1565 v2.4ZD
The PC1565 v2.4ZD software incorporates several new
features and changes. The most important additions are
listed below:
Number of Zones
System expandable to 8 zones using keypad zone inputs
and to 32 zones using the PC5132 wireless expansion
module (See 1.2 ‘Additional Devices’ on page 2.)
New Options & Features
• New access code attribute option determines whether
the bell squawks on arming/disarming. (See ‘[*][5]
Programming Access Codes’ on page 10.)
• New option allows bell squawk on Away arming only
(See 5.17 ‘Arming/Disarming Options’ on page 23.)
• Expand hardwire zones from 6 to 12 using the Zone
Doubling option (See 5.5 ‘Zone Doubling’ on page 17.)
• Users can restart the exit delay once by pressing the
Away key.
• Status Alarm Memory Output
• PC5208 Support
New Downloading Software
Downloading software DLS-3 v1.3 or higher must be
used. Do not attempt to perform downloading/uploading
functions with other software versions.
PC1565 Module Compatibility
Module Compatible? Comments
Classic Escort (VPM-1) No
Escort5580 No
PC-16 Out No
PC5204 No
PC5208 Yes
PC5108 No
PC5108L No
PC5132 v1.X Yes No support for Wireless Keys, Pendants or Handheld Keypads
PC5132 v2.X Yes No identified Wireless Keys support
PC5132 v3.X Yes
PC5506 No
PC55XX Yes No Keypad zone support
PC55XXZ Yes
PC5509 Yes
LCD5500 v1.X Yes No Keypad zone support; Some display messages not supported
LCD5500Z v2.X Yes
LCD5501Z Yes
LCD600 No
LED615 No
SL-XX No
PC1500RK No
PC1555RKZ Yes
PC5908 No
PC5928 No
PC5400 Printer
Module v1.X to v2.1
Yes Some printing messages not supported
PC5400 Printer
Module v2.2
Yes
Links1000 Yes
Links2150 Yes
Links2450 Yes
©2002 Digital Security Controls Ltd.
Toronto, Canada • www.dsc.com
Printed in Canada 29005155 R002
Direct all comments concerning this
publication to pubs@dscltd.com.
