Appendix A: Reporting Codes
The following tables contain Contact ID and Automatic SIA for-
mat reporting codes. For more information on reporting code
formats and notes about individual reporting codes, see sec-
tions 5.9 ‘Communicator – Reporting Codes’ on page 18 and
5.10 ‘Communicator – Reporting Formats’ on page 19.
Contact ID
The first digit (in parentheses) will automatically be sent by the
control. The second two digits are programmed to indicate spe-
cific information about the signal.
For example, if zone 1 is an entry/exit point, you could program
the event code as [34]. The central station would receive the
following:
*BURG - ENTRY/EXIT - 1
where the “1” indicates which zone went into alarm.
SIA Format - Level 2 (Hardcoded)
The SIA communication format used in this product follows the
level 2 specifications of the SIA Digital Communication Stan-
dard - January 1996. This format will send the Account Code
along with its data transmission. The transmission would look
similar to the following at the receiver:
N Ri01 BA 01
N= New Event
Ri01 = Partition /Area Identifier
BA = Burglary Alarm
01 = Zone 1
Section # Reporting Code Code Sent When...
Dialer
Direction*
Contact
ID Codes
SIA Auto Rep
Codes**
[320] Zone Alarms zone goes into alarm A/R (1) 3A See Table 3
[324] Zone Restorals alarm condition has been restored A/R (1) 3A
[330]
[334]
Zone Tamper/Restoral zone exhibits a tamper condition/tamper condition
restored
T/R (1) 44 TA-ZZ/TR-ZZ
[328] Duress Alarm duress code entered at keypad A/R (1) 21 HA-00
[328] Opening After Alarm system disarmed with alarm in memory A/R (4) A6 OR-00
[328] Recent Closing alarm occurs within two minutes of system arming A/R (4) 59 CR-00
[328] Zone Expander Supervisory
Alarm/Rest.
panel loses/restores supervisory transmission over the
Keybus from enrolled PC5132 module or keypads with
zone inputs
A/R (1) 43 UA-00/UH-00
[328] Cross Zone (Police Code)
Alarm
two zones on the same partition go into alarm during
any given armed-to-armed period (incl. 24-hr zones)
A/R (1) 4A BV-00
[329] [F] Key Alarm/Rest. Keypad fire alarm (alarm and restore rep. codes sent
together)
A/R (1) 15 FA-00/FH-00
[329] [A] Key Alarm/Rest. Keypad auxiliary alarm (alarm and restore rep. codes
sent together)
A/R (1) AA MA-00/MH-00
[329] [P] Key Alarm/Rest. Keypad panic alarm (alarm and restore rep. codes sent
together)
A/R (1) 2A PA-00/PH-00
[329] PGM2 Alarm/Rest. a panic button wired to PGM2 is pressed / access code
is entered (PGM2 programmed as option [23] or [24])
A/R (1) 4A UA-99/UH-99
[338] General System Tamper/
Rest.
enrolled module with tamper inputs has a tamper alarm/
all module tampers restored
T/R (1) 45 TA-00/TR-00
[338] Keypad Lockout max. number of incorrect access codes has been
entered at a keypad
T/R (4) 21 JA-00
[339-343] Closings system armed (user 01-34, 40-42 indicated) O/C (4) A2 CL-UU
[343] Partial Closing one or more zones bypassed when system armed O/C (4) 7A CG-ZZ
[343] Special Closing Closing (arming) using one of the following methods:
quick arm, auto-arm, keyswitch, function key, mainte-
nance code, DLS software
O/C (4) AA CL-00
[344-348] Openings system disarmed (user 01-34, 40-42 indicated) O/C (4) A2 OP-UU
[348] Auto-arm Cancellation auto-arm cancelled O/C (4) A5 CE-00
[348] Special Opening Opening (disarming) using one of the following meth-
ods: keyswitch, maintenance code, DLS software
O/C (4) AA OP-00
[349-350] Battery Trouble/Rest. PC1565 battery is low/battery restored MA/R (3) A2 YT-00/YR-00
* A/R = alarms/restorals; T/R = tampers/restorals; O/C = openings/closings; MA/R = miscellaneous alarms/restorals; T = test transmissions
** UU = user number (user01-42); ZZ = zone number (01-08)
