PowerSeries System Keypads
Function
Lights
Zone
Lights
Status
Lights
Function
Buttons
Emergency
Keys
[
PC5532Z
Your installer may have installed
one of these LED keypads if you
have 16 or fewer zones on your sys-
tem. These keypads operate in the
same way as the PC5532 keypad.
PC5508Z
PC5516Z
Status
Lights
Number
Pad
Function
Buttons
Liquid
Crystal
Display (LCD)
Arrow
(Scroll)
Keys
Emergency
Keys
LCD5501Z
LCD5500Z
