Section 5: Troubleshooting
1
st
Layer 2
nd
Layer 3
rd
Layer
01 System Trouble 01 AC
02 Battery Trouble
03 Tamper
04 Hardware Fault
05 Loss of Time
06 RF Jam
02 Zone 01 AC Trouble 1-128
02 Battery Trouble 1-128
03 Tamper 1-128
04 Fault (Supervision) 1-128
05 Not Networked 1-128
06 Fire/CO Trouble 1-128
03 Siren 01 Future Use 1-16
02 Battery Trouble 1-16
03 Tamper 1-16
04 Fault (Supervision) 1-16
05 Not Networked 1-16
04 Keypad 01 AC 1-9
02 Battery Trouble 1-9
03 Tamper 1-9
04 Fault (Supervision) 1-9
05 Not Networked 1-9
05 Repeater 01 AC 1-8
02 Battery Trouble 1-8
03 Tamper 1-8
04 Fault (Supervision) 1-8
05 Not Networked 1-8
06 RF Jam 1-8
06 Wireless Key 01 Future Use 1-32
02 Battery Trouble 1-32
03 Future Use 1-32
04 Future Use 1-32
05 Not Networked 1-32
07 Communication 01 Receiver Unavailable
02 FTC Trouble
receiver 1-4
03 Receiver Supervision Trouble
04 Cellular Trouble
05 Ethernet/WiFi Trouble
06 Remote Shutdown
