Appendix 2: Reporting Codes
Appendix 2: Reporting Codes
The following tables contain Contact ID and Automatic SIA format reporting codes.
Contact ID
Each of the digits indicate specific information about the signal. For example, if zone 1 is an entry/exit point, the event code
contains [34]. The central monitoring station would receive the following:
*BURG - ENTRY/EXIT - 1 where the “1” indicates which zone went into alarm.
See "Contact ID and SIAZone Alarm/Restore Event Codes" on page 51 for code definitions.
SIA Format - Level 2 (Hard Coded)
The SIA communication format used in this product follows the level 2 specifications of the SIA Digital Communication
Standard - October 1997. This format sends the account code along with its data transmission. The transmission appears
similar to the following at the receiver:
N ri1 BA 01
N = New Event
ri1 = Partition /Area Identifier
BA = Burglary Alarm
01 = Zone 1
A system event uses the Area Identifier ri00.
Contact ID and SIAZone Alarm/Restore Event Codes
Section # Definition
Dialer Dir-
ection*
Automatic Contact ID
Codes
SIA Auto Rep Codes**
Zone Events
Zone Alarms A/R
see "Contact ID & SIA Zone Alarm/Restore Event Codes" on
page 56" for details.
Zone Restores A/R
Zone tamper/restore MA/R E(3)83-ZZZ / R(3)83-ZZZ TA-ZZZ / TR-ZZZZ
Zone fault/restore MA/R E(3)8A-ZZZ / R(3)8A-ZZZ UT-ZZZZ / UJ-ZZZZ
Tamper Events
Keypad 1 tamper/restore alarm T/R E(3)83-601 / R(3)83-601 TA-0601 / TR-0601
Keypad 2 tamper/restore alarm T/R E(3)83-602 / R(3)83-602 TA-0602 / TR-0602
Keypad 3 tamper/restore alarm T/R E(3)83-603 / R(3)83-603 TA-0603 / TR-0603
Keypad 4 tamper/restore alarm T/R E(3)83-604 / R(3)83-604 TA-0604 / TR-0604
Siren 1 tamper/restore alarm T/R E (3)83-801 / R (3)83-801 TA-0801 / TR-0801
Siren 2 tamper/restore alarm T/R E(3)83-802 / R (3)83-802 TA-0802 / TR-0802
Siren 3 tamper/restore alarm T/R E(3)83-803 / R (3)83-803 TA-0803 / TR-0803
Siren 4 tamper/restore alarm T/R E (3)83-804 / R (3)83-804 TA-0804 / TR-0804
Siren 5 tamper/restore alarm T/R E(3)83-805 / R (3)83-805 TA-0805 / TR-0805
Siren 6 tamper/restore alarm T/R E(3)83-806 / R (3)83-806 TA-0806 / TR-0806
Siren 7 tamper/restore alarm T/R E(3)83-807 / R (3)83-807 TA-0807 / TR-0807
Siren 8 tamper/restore alarm T/R E(3)83-808 / R (3)83-808 TA-0808 / TR-0808
Siren 9 tamper/restore alarm T/R E(3)83-809 / R (3)83-809 TA-0809 / TR-0809
Siren 10 tamper/restore alarm T/R E (3)83-810 / R (3)83-810 TA-0810 / TR-0810
Siren 11 tamper/restore alarm T/R E(3)83-811 / R (3)83-811 TA-0811 / TR-0811
