DSE 333 - Ats - Generator - Mains Interconnection Wiring Dse 333

Fax 01933 677916
Phone 01933 677911
STEPHILL GENERATORS
Drawn
R Golding
Drawing Number
SW18015
Description
ATS - GENERATOR - MAINS
INTERCONNECTION WIRING
DSE 333
Last Number Used
47
Revision
New drawing
DateIssue
01-04-14
A
BATTERY +VE
BATTERY -VE
REMOTE START -VE
GREEN/YELLOW
BLUE
BROWN
EARTH
V BLACK
N BLUE
W GREY
U BROWN
ATS PANEL DSE333
(13) (32) (61) REMOTE START -VE
1.5mm (MAX 10M)
(2) (2) (2) BATTERY +VE
(1) (1) (1) BATTERY -VE
GREEN/YELLOW
Cable to be sized as per Iee regulations.
BLUE
BROWN
EARTH
Cable to be sized as per iee regulations.
V BLACK
N BLUE
W GREY
U BROWN
GENERATOR
L1
N N
L1
3 PHASE
L1
L3
N
L2
N
L3
L1
L2
3 PHASE
1 PHASE 1 PHASE
DC CONTROL DC CONTROL
DEEP SEA 3110 DEEP SEA 6110
3
1
4
3
1
4
DEEP SEA 7310
7310 Wiring added.
19-11-15
B
