Issue 1 1
1 SAFETY
Warning
ATS Panel should only be installed, maintained or serviced by a qualified electrician.
The generator set may start without warning whilst in AUTO mode.
Before undertaking any service or maintenance work, ensure the mains and generator supply are
isolated and generator is switched to off.
The generator is supplied with the battery disconnected/isolated for safety reasons and should not
be re-connected until all connections have been made.
Because of the nature of the equipment and the permanent mains connection, the terminals within
the generator may be LIVE even if the generator itself is not running.
2 INSTALLATION
Make sure that the Generator is at least one metre away from any building during operation.
Operate in a well ventilated unconfined area, so that fumes can be properly dispersed.
Silencer outlet should be facing an open area to prevent fumes being recirculated.
Consideration will also need to be made for refuelling and maintenance.
If installing in a confined area please consult manufacturer.
2.1 ELECTRICAL INSTALLATION
2.2 AC Wiring
Please ensure the correct cross sectional area of cable between the Alternator/Panel and
Distribution board used is adequate to carry the full rated continuous output of the generator,
allowing for de-rating in high ambient temperatures. Please consult IEE regulations as per the
correct sizing of cable and other issues regarding wiring. Flexible cable is recommended for
alternator connections allowing for a generous loop before the cable enters the alternator terminal
box because of the vibration caused by the set starting. If this is not possible a terminal box can be
fitted nearby and flex fitted between this and the generator terminal box. These precautions will not
be needed when fixing to a control box which is not attached to the Alternator. Please refer to
Wiring diagram.
2.3 DC WIRING
For the DC wiring we recommend 1.5mm if the generator is more than 10Meters away please
consult manufacturer for cable sizing. Please refer to Wiring diagram.
3 START GUIDE
Note For full instructions download handbook on DSE website http://www.deepseaplc.com/home/
This section provides a quick start guide to the module’s operation.
