DIMENSIONS
240.0mm x 181.1mm x 41.7mm
(9.4” x 7.1” x 1.6”)
PANEL CUTOUT
:
220mm x 160mm
(8.7” x 6.3”)
ADJUSTABLE PARAMETERS
Front Panel Configuration Editor
Section Parameter as shown on display Factory Settings
Display
Contrast 53%
Language English, others.
Current Date and Time
hh:mm
Timers
LCD Page Timer 5m
Scroll Delay
2s
ss
s
Battery Under Voltage Warning
Delay
1m
Battery Over Voltage Warning Delay 1m
Start Delay Off Load 5s
Start Delay On Load 5s
Start Delay Telemetry 5s
Start Delay Mains Fail 5s
Mains Transient Delay 2s
Return Delay 30s
Mains Transient Time 0.7s
Mains
Under Voltage Trip 184V
Over Voltage Trip 276V
Under Frequency Trip 45Hz
Over Frequency Trip 55Hz
CT Primary 600A
CT Secondary 5A
Mains KW Rating 345kW
Mains KVar Rating 258kW
AC System 3 Phase 4 Wire
Bus
Start Delay On Load 5s
Insufficient Capacity Delay 1s
Battery Under Volts Warning Active
Battery Under Volts Warning Delay 1m
Battery Under Volts Warning 10V
Battery Over Volts Warning Active
Battery Over Volts Warning Delay 1m
Battery Over Volts Warning 30V
Load Level For More Sets 80%
Load Level For Less Sets 70%
Load Ramp Rate 3%/s
Schedule
Scheduler Inactive
Schedule Loading On Load
Inactive (Only Available
When Scheduler Is Active)
Schedule Period
Weekly (Only Available
When Scheduler Is Active)
Schedule Time & Date Selection
(1-16)
Press
to begin editing
then or when
selecting the different
parameters in the
scheduler.
CCESSING THE ‘RUNNING’ CONFIGURATION EDITOR
• The ‘running’ editor can be entered while the engine is running. All protections remain active if the
engine is running while the running editor is entered.
• Press and hold the button to enter the running editor.
ADJUSTABLE PARAMETERS (Running editor)
• Enter the editor as described above.
•
Press the up or down buttons to cycle to the section you wish to view/change.
•
To Edit the parameter press the button to enter edit mode. The parameter begins to flash to
indicate that you are editing the value.
• Press the up
or down
buttons to change the parameter to the required value.
• Press the button to save the value. The parameter ceases flashing to indicate that it has been
saved.
•
To exit the editor at any time , press and hold the
button.
Running Editor
Section
Parameter as shown on display
Factory Settings
Display
Contrast 53%
Language English
Load parallel power 30%
Load Power factor 63%
Commissioning screens Inactive
)
Mains decoupling test mode (Stop mode only) Inactive
Voltage adjust (manual mode only engine running
breaker open)
0V L-N
Frequency adjust (manual mode only engine running
breaker open)
0 Hz
