3. SAFETY-RELATED REGULATIONS
For connecting, programming and servicing, the fol-
lowing regulations must be observed (the list is not
exhaustive).
• EN 12453 (Safety in use of power operated doors -
Requirements)
• EN 12445 (Safety in use of power operated doors -
Test methods)
• EN 12978 ((Industrial commercial and garage doors
and gates - safety devices for power operated doors
- Requirements and test methods)
References to additional, additionally accepted stand-
ards must also be observed, such as:
• EN 60204-1 (Safety of machinery, electrical equip-
ment of machines, part 1: general requirements)
• EN 12100-1 (Safety of machinery, basic concepts,
general principles for design. Basic terminology,
methodology)
• EN 60335-1 (Household and similar electrical appli-
ances - Safety)
• EN 60335-2-103 (Particular requirements for drives
for gates, doors and windows)
• Committee for Workplaces (ASTA)
• Workplace regulation ASR A1.7 (“Doors and gates“)
4. SAFETY INSTRUCTIONS
DANGER !
Failure to comply with the documentation could result in
life-threatening danger!
Be sure to follow all the safety instructions in this docu-
ment.
DANGER !
Life-threatening danger due to electric shock!
• It is vital that you disconnect the operator system
from the power supply before commencing cabling
work. Take measures to ensure that the power sup-
ply remains disconnected for the duration of the
work.
NOTICE !
For a three-phase current, a clockwise rotating field is
required.
WARNING !
• Ensure that children can not play with the door con-
trols or the hand transmitter.
• Before setting the door in motion, make sure that no
persons or objects are within the danger zone of the
door.
• Check all the existing emergency command devices.
• Pay attention to potential crushing and shearing
zones in the door system.
• Never touch a running door, the guide rail or any
moving parts.
INFORMATION !
For a permanent connection, an all-pole main switch
must be used.
WARNING !
• The control and the drive must be installed with its
intended covers and guards. It is important to en-
sure the correct fit of any seals and couplings are
tightened correctly.
• The mains voltage must correspond to the voltage
stated on the type plate.
• The mains voltage must be the same as the voltage
of the drive.
• For a three-phase connection, only 3-way automatic
circuit breakers (10A) may be used.
• Before switching on the controls for the first time, a
check must be carried out after completing the wir-
ing to ensure that all the motor connections at the
motor and at the controls are securely fixed.
• SAFETY RELAYS:
• If the control unit is a version without three safety
relays, the door manufacturer/installer is responsi-
ble of preventing any dangerous situation if one of
the contactors is welded.
To Next Page
