11. TECHNICAL DATA
Enclosure data: 293 x 190 x 110 mm, ABS
Protection: IP65 (with appropriate cable glands)
Installation: Vertical on a vibration free and flat wall, min. hight: 1.1 m
Mass: ca. 1.8 kg
Humidity: Up to 93% RH non-condensing
Temperature range: Operating: -10° C … +50°C
PCB dimension: 225 x 163 x 80 mm
Supply voltage:
400 V/AC ± 10% L1,L2,L3,N,PE
230 V/AC ± 10% L1,L2,L3,PE
230 V/AC ± 10% L, N
50/60Hz, Mains fuse max: 3 x 10A
Transformer:
Max 13 VA , VDE 0570/EN61558
Primary 230VAC winding is thermal protected by built-in thermal transform-
er fuse. Both secondary windings are overload protected by multifuses.
Motor output:
Max motor load by 3 x 400V/AC: 4 kW
Max motor load by 3 x 230V/AC: 2.3 kW
Max motor load by 1 x 230V/AC: 1.5 kW
Max motor current: 8,5 A
Operating duty cycle: 60% at max. 120 s runtime
Consumption control: Max. 13 VA
Control voltage: 24 VDC, max. 250 mA; protected by polyfuse
Electronic limits: RS485, Data+ Data-, terminated with 120 Ohm
Emergency stop, Stop, Thermo Function as normal stop command and disconnect power to contactor coils.
Safety edge input:
• PNE/air switch
• Electric type - 8k2 termination ± 10%
• Optical type (Fraba OSE or Dalmatic TSS/RSS)
Performance level C, Category 2
Optical safety edge:
Input voltage high (green): 2.5 - 5.0 Volt
Input voltage low (green): < 0.5 Volt
Input frequency range (green): 250 – 2000 Hz. (50% duty-cycle)
Pulse interval maximum (green): 7.0 ms (when not 50% duty cycle)
Photo input (X3-19,20,21,22 ): External photo, 24VDC (e.g. self contain photo cell)
24 VDC Output (X3-18, X3-19): 24VDC ± 20% (non-regulated), Max load: 250mA
Option relay output (K3 + X17): Change over contact: 230VAC/5A
