DTronics Q-5 - Module and Pad Mounting

1
2
Insert the module into the rack clamp, x it in a comfortable
position and tighten the screw.
1
Place the bassdrum-pad onto the plate 1, tighten the screw.
4
3
Set up the plates 3 and 4 and tighten the screw
2
3
1
2
4
3
Set up plate 1,2.3 and 4 as shown above and tighten
the screws.
4
Set up plate 2 on the backside of the pad and tighten the
screw.
33
Part 1: Assembly instruction
33
2
1. Take out the wing nut and felt washer.
2. Place the cymbal over the tilter peg. Put the felt washer and
wing nut onto the cymbal. Tilt the cymbal to your preference.
Assembling the module
Assembling the kick
1
HiHat
Cymbals
Crash + Ride
Cymbals
