DTS 03.MS014.EBLFP User Manual

36
DMX CHANNEL
17
Parameter: GOBO
DMX value
Function
000-020
Open
021-041
Gobo 1
042-062
Gobo 2
063-083
Gobo 3
084-104
Gobo 4
105-125
Gobo 5
126-146
Gobo 6
147-167
Gobo 7
168-188
Gobo 8
189-207
Gobo 9
208-213
Speed rotation 1 min
214-219
Speed rotation 2
220-225
Speed rotation 3
226-231
Speed rotation 4
232-237
Speed rotation 5
238-243
Speed rotation 6
244-249
Speed rotation 7
250-255
Speed rotation 8 max
DMX CHANNEL
18
Parameter: GOBO MODE
DMX value
Function
000-127
Gobo rotation mode
128-255
Gobo index mode
DMX CHANNEL
19
Parameter: GOBO ROTATION/INDEX
GOBO MODE ROTATION
DMX value
Function
000-009
Stop
010-127
Left rotation (max to min)
128-137
Stop
138-255
Right rotation (min to max)
GOBO MODE INDEX
DMX value
Function
000-255
Gobo index coarse
DMX CHANNEL
20
Parameter: GOBO INDEX FINE
DMX value
Function
000-255
Gobo index fine
DMX CHANNEL
21
Parameter: GOBO SHAKE
DMX value
Function
000-009
Stop
010-022
Gobo shake R-L speed 1
023-035
Gobo shake R-L speed 2
036-048
Gobo shake R-L speed 3
049-061
Gobo shake R-L speed 4
062-074
Gobo shake R-L speed 5
075-087
Gobo shake R-L speed 6
088-100
Gobo shake R-L speed 7
101-113
Gobo shake R-L speed 8
114-126
Gobo shake R-L speed 9
127-138
Stop
139-151
Gobo shake L-R speed 1
152-164
Gobo shake L-R speed 2
165-177
Gobo shake L-R speed 3
178-190
Gobo shake L-R speed 4
191-203
Gobo shake L-R speed 5
204-216
Gobo shake L-R speed 6
217-229
Gobo shake L-R speed 7
230-242
Gobo shake L-R speed 8
243-255
Gobo shake L-R speed 9
