DMX CHANNEL
22
Parameter: FIXED GOBO
DMX value
Function
000-018
Open
019-037
Gobo 1
038-056
Gobo 2
057-075
Gobo 3
076-094
Gobo 4
095-113
Gobo 5
114-132
Gobo 6
133-151
Gobo 7
152-170
Gobo 8
171-189
Gobo 9
190-207
Gobo 10
208-213
Speed rotation 1 min
214-219
Speed rotation 2
220-225
Speed rotation 3
226-231
Speed rotation 4
232-237
Speed rotation 5
238-243
Speed rotation 6
244-255
Speed rotation 7 max
DMX CHANNEL
23
Parameter: FIXED GOBO SHAKE
DMX value
Function
000-009
Stop
010-022
Gobo shake R-L speed 1
023-035
Gobo shake R-L speed 2
036-048
Gobo shake R-L speed 3
049-061
Gobo shake R-L speed 4
062-074
Gobo shake R-L speed 5
075-087
Gobo shake R-L speed 6
088-100
Gobo shake R-L speed 7
101-113
Gobo shake R-L speed 8
114-126
Gobo shake R-L speed 9
127-138
Stop
139-151
Gobo shake L-R speed 1
152-164
Gobo shake L-R speed 2
165-177
Gobo shake L-R speed 3
178-190
Gobo shake L-R speed 4
191-203
Gobo shake L-R speed 5
204-216
Gobo shake L-R speed 6
217-229
Gobo shake L-R speed 7
230-242
Gobo shake L-R speed 8
243-255
Gobo shake L-R speed 9
DMX CHANNEL
24
Parameter: IRIS
DMX value
Function
000-009
Open
010-246
Linear iris from open to closed
247-255
Closed
DMX CHANNEL
25
Parameter: IRIS MACROS
DMX value
Function
000-009
No effect
010-063
Iris pulse at different speed from min to max
064-117
Iris pulse with flash closing from min to max
118-171
Iris pulse with flash opening from min to max
172-213
Iris pulse with flash closing combined with zoom from min to max
214-255
Iris pulse with flash opening combined with zoom from min to max
