DTS EVO - Gobo and Focus Calibration

29
SMOOTH-FROST ZERO ALIGNMENT
Effects-Frost blade zero position
setting
CALIBRATION
FIXED GOBO
MENU ENTER DOWN UP
MOTORS ALIGNMENT
134
CALIBRATION
FIXED G. 12 MM
MENU ENTER DOWN UP
MOTORS ALIGNMENT
129
CALIBRATION
SM-FR ZERO
MENU ENTER DOWN UP
MOTORS ALIGNMENT
125
CALIBRATION
SMOOTH 1 PATH
MENU ENTER DOWN UP
MOTORS ALIGNMENT
195
CALIBRATION
SMOOTH 2 PATH
MENU ENTER DOWN UP
MOTORS ALIGNMENT
210
CALIBRATION
FROST PATH
MENU ENTER DOWN UP
MOTORS ALIGNMENT
222
CALIBRATION
PR.DEPTH ZERO
MENU ENTER DOWN UP
MOTORS ALIGNMENT
85
CALIBRATION
PR.DEPTH PATH
MENU ENTER DOWN UP
MOTORS ALIGNMENT
128
CALIBRATION
DYNA-PR. ZERO
MENU ENTER DOWN UP
MOTORS ALIGNMENT
117
CALIBRATION
DYNA-PR. PATH
MENU ENTER DOWN UP
MOTORS ALIGNMENT
135
CALIBRATION
8F-PRISM ZERO
MENU ENTER DOWN UP
MOTORS ALIGNMENT
130
CALIBRATION
8F-PRISM PATH
MENU ENTER DOWN UP
MOTORS ALIGNMENT
139
CALIBRATION
PRISM INDEX
MENU ENTER DOWN UP
MOTORS ALIGNMENT
128
CALIBRATION
FOCUS ZERO
MENU ENTER DOWN UP
MOTORS ALIGNMENT
97
CALIBRATION
ZOOM ZERO
MENU ENTER DOWN UP
MOTORS ALIGNMENT
81
CALIBRATION
ZOOM PATH
MENU ENTER DOWN UP
MOTORS ALIGNMENT
182
CALIBRATION
FOCUS GOBO 0
MENU ENTER DOWN UP
MOTORS ALIGNMENT
138
CALIBRATION
FOCUS GOBO 9
MENU ENTER DOWN UP
MOTORS ALIGNMENT
171
CALIBRATION
FOCUS F.G. 1
MENU ENTER DOWN UP
MOTORS ALIGNMENT
138
CALIBRATION
FOCUS F.G. 17
MENU ENTER DOWN UP
MOTORS ALIGNMENT
134
15.1 Calibration mode
FIXED GOBO WHEEL ALIGNMENT
To align Fixed gobo wheel
SMOOTH 2 PATH ALIGNMENT
Effect 2 filter max excursion
calibration
FROST PATH ALIGNMENT
Frost filter max excursion
calibration
PRISM DEPTH PATH ALIGNMENT
Prisms group max excursion calibration
DYNA-PRISM ZERO ALIGNMENT
Dyna Prism Zero position setting
DYNA-PRISM PATH ALIGNMENT
Dyna Prism max excursion
calibration
8 FACET PRISM ZERO ALIGNMENT
8 facet prism zero position setting
PRISM INDEX ALIGNMENT
To adjust index position of the
prisms
FOCUS ZERO ALIGNMENT
Focus lens zero position setting
ZOOM ZERO ALIGNMENT
Zoom lens zero position setting
PRISM DEPTH ZERO ALIGNMENT
Prisms group zero position setting
8 FACET PRISM PATH ALIGNMENT
8 facet prism max excursion
calibration
ZOOM PATH ALIGNMENT
Zoom lens max excursion
calibration
FIXED GOBO 12 mm ALIGNMENT
To align the 12 mm fixed gobo open
SMOOTH 1 PATH ALIGNMENT
Effect 1 filter max excursion
calibration
FOCUS GOBO 0-9
Focusing of the 9 rotating gobos
FOCUS FIXED GOBOS 1-17
Focusing of the 17 fixed gobos
