DTS EVO - Calibration Mode Procedures; Motor Alignment Calibration; Filter and Prism Calibration

28
GOBO INDEX ALIGNMENT
To adjust Gobo index position of
the Rotating gobos
CALIBRATION
PAN
MENU ENTER DOWN UP
MOTORS ALIGNMENT
127
CALIBRATION
TILT
MENU ENTER DOWN UP
MOTORS ALIGNMENT
145
CALIBRATION
DIMMER 1 ZERO
MENU ENTER DOWN UP
MOTORS ALIGNMENT
81
CALIBRATION
DIMMER 2 ZERO
MENU ENTER DOWN UP
MOTORS ALIGNMENT
86
CALIBRATION
DIMMER 1 PATH
MENU ENTER DOWN UP
MOTORS ALIGNMENT
156
CALIBRATION
DIMMER 2 PATH
MENU ENTER DOWN UP
MOTORS ALIGNMENT
159
CALIBRATION
SHUTTER ZERO
MENU ENTER DOWN UP
MOTORS ALIGNMENT
128
CALIBRATION
SHUTTER PATH
MENU ENTER DOWN UP
MOTORS ALIGNMENT
128
CALIBRATION
COLOUR WHEEL
MENU ENTER DOWN UP
MOTORS ALIGNMENT
120
CALIBRATION
CYAN ZERO
MENU ENTER DOWN UP
MOTORS ALIGNMENT
129
CALIBRATION
CYAN PATH
MENU ENTER DOWN UP
MOTORS ALIGNMENT
190
CALIBRATION
MAGENTA ZERO
MENU ENTER DOWN UP
MOTORS ALIGNMENT
109
CALIBRATION
MAGENTA PATH
MENU ENTER DOWN UP
MOTORS ALIGNMENT
190
CALIBRATION
YELLOW ZERO
MENU ENTER DOWN UP
MOTORS ALIGNMENT
97
CALIBRATION
YELLOW PATH
MENU ENTER DOWN UP
MOTORS ALIGNMENT
181
CALIBRATION
CTO ZERO
MENU ENTER DOWN UP
MOTORS ALIGNMENT
112
CALIBRATION
CTO PATH
MENU ENTER DOWN UP
MOTORS ALIGNMENT
168
CALIBRATION
GOBO 0-8
MENU ENTER DOWN UP
MOTORS ALIGNMENT
121
CALIBRATION
GOBO 9
MENU ENTER DOWN UP
MOTORS ALIGNMENT
122
CALIBRATION
GOBO INDEX
MENU ENTER DOWN UP
MOTORS ALIGNMENT
128
15.1 Calibration mode
PAN ALIGNMENT
To align Pan position
TILT ALIGNMENT
To align Tilt position
DIMMER 1 ZERO ALIGNMENT
Dimmer blade 1 zero position setting
DIMMER 1 PATH ALIGNMENT
Dimmer blade 1 max excursion
calibration
COLOUR WHEEL ALIGNMENT
To align Colour wheel
CYAN ZERO ALIGNMENT
Cyan filter blade zero position
setting
CYAN PATH ALIGNMENT
Cyan filter blade max excursion
calibration
MAGENTA ZERO ALIGNMENT
Magenta filter blade zero position
setting
MAGENTA PATH ALIGNMENT
Magenta filter blade max
excursion calibration
YELLOW ZERO ALIGNMENT
Yellow filter blade zero position
setting
YELLOW PATH ALIGNMENT
Yellow filter blade max excursion
calibration
CTO ZERO ALIGNMENT
CTO filter blade zero position setting
CTO PATH ALIGNMENT
CTO filter blade max excursion
calibration
GOBO 0-8 ALIGNMENT
To align the global position of the
Rotating gobo wheel (gobo 0 – 8)
GOBO 9 ALIGNMENT
To align Gobo 9 / Open Studio
of the Rotating gobo wheel
DIMMER 2 ZERO ALIGNMENT
Dimmer blade 2 zero position setting
DIMMER 2 PATH ALIGNMENT
Dimmer blade 2 max excursion
calibration
SHUTTER ZERO ALIGNMENT
Shutter blade zero position setting
SHUTTER PATH
Shutter blade max excursion
calibration
