SWC Input Operation

1. Volume Up (+) 4. Preset (+) 7. Seek/Track Up (+) 10. BT Talk
2. Volume Down (-) 5. Preset (-) 8. Seek/Track Down (-) 11. BT End
3. Mute 6. Mode 9. Band
The built-in SWC Interface is compatible with PAC steering wheel control modules. The PAC SWI-RC is recommended.
A third-party adapter must be used in order for the XDVD276BT to be compatible with any steering wheel controls.
The following controls are available for most vehicles:
Note:
Not all OE steering wheel functions may be supported by the XDVD276BT.

PAC SWI-RC Installation Hints
1. Set "Radio Select Switch". Set the SWI-RC to position 7 - "Pioneer/Other/Sony".
2. Programming - Use the Pioneer/Sony/Other radio function mapping order for Dual branded head units.
3. When programming the SWI-RC, if a function is not supported (or not desired), then the function MUST be skipped
as per the PAC SWI-RC instructions.
4. The SWC function MUST be programmed in the correct order per the PAC SWI-RC radio function mapping order
instructions.
Function
Order
Function Mapping
Center Pin (Ring) Voltage
(Function Select)
Tip Pin Voltage
1 Volume + H 5.0v 2.07
2 Volume - H 5.0v 2.32
3 Mute H 5.0v 1.01
4 Preset + L 0.0v 1.54
5 Preset - L 0.0v 1.81
6 Source H 5.0v 0.6
7 Seek + / Track + H 5.0v 1.54
8 Seek - / Track - H 5.0v 1.81
9 Band H 5.0v 2.73
10 BT Talk L 0.0v 0.6
10 BT End L 0.0v 1.01
SWI-RC (3.3VDC Reference)
22
DV712 OPERATION
