MXD50 INSTALLATION
Preparation
Please read entire manual before installation.
Before You Start
• Disconnect negative battery terminal. (consult a qualified technician for instructions)
•Avoid installing the unit where it would be subject to high temperatures, such as
from direct sunlight, or where it would be subject to dust, dirt or excessive
vibration.
Getting Started
• Remove 2 transit screws located on
top of the unit.
• Insert the supplied keys into the
slots as shown, and slide the unit
out of the mounting sleeve.
• Install mounting sleeve into
opening, bending tabs to secure.
• Connect wiring harness and
antenna. (consult a qualified
technician if you are unsure).
•Test for correct operation and slide
into mounting sleeve to secure.
TYPICAL MOUNTING METHOD
