MXD55 OPERATION
Control Locations
Release
Power
Volume/Audio Adjustment
Tuner Scan
Display
Auto Store/Preset Scan
EQ
Tune/Track Down
Eject
Tune/Track Up
1
2
3
4
5
6
7
8
9
10
Mode
Bass Boost
Preset 6
Preset 5
Preset 4
Preset 3/CD Intro
Preset 2/CD Random
Preset 1/CD Repeat
Play/Pause/Band
Mute
11
12
13
14
15
16
17
18
19
20
20 19 18 17 16 15 14 13 12 11
1 2 3 4 5 6 7 8 9 10
Before installation, remove trim ring and install supplied
Phillips head #1 x 7/32” screw through left side of mounting
frame into faceplate.
*Semi-permanent
Faceplate Attachment
