Dual XHD6430 - Audio Settings and Equalizer; Bass, Treble, Balance, Fader Adjustments; Equalizer Presets and User EQ; Source Volume Level Control

8
XHD6430 OPERATION
Press ESCtoexitanymenuadjustmentmode.
Press AUDIO/MENUmomentarilytoselectbetweenBass,
Treble,Balance,Fader,EQ,Subwoofer*andSourceVolume
Level.
Press AUDIO/MENU until BASSappears,thenrotate
thevolume knobleft/righttoadjust(-6minimum/+6
maximum).
Press AUDIO/MENU until TREBLEappears,thenrotate
thevolume knob left/righttoadjust(-6minimum/+6
maximum).
Note:BassandTreblesettingsaresavedastheUSEREQ
setting.
Note: BassandTreblesettingsareretainedforeachmode
individually.
Press AUDIO/MENU until BALANCEappears,thenrotatethe
volume knobleft/righttoadjust(BALL12toBALR12).L=R
representsequalbalance.
Press AUDIO/MENU until FADERappears,thenrotatethe
volume knobleft/righttoadjust(FADERF12toFADERR12).
F=Rrepresentsequalfader.
Press AUDIO/MENU until EQappears.Rotatethevolume
knobleft/righttoselectbetweenFLAT(default),POP,JAZZ,
CLASSIC,BEAT,ROCKandUSERequalizationcurves.Press
SELECTtoconfirm.AnymanualadjustmenttotheBassor
TreblesettingsareautomaticallysavedasUSER.
Press AUDIO/MENU until SUB-Wappears,thenrotatethe
volume knobleft/righttoadjust(0-12).Adjustinglevelsto0
turnsthesubwooferoff.
Thesourcevolumelevelcontrolallowsagainadjustmentfor
eachaudiosource:AM,FM,CD,AUX,USB,operationofiPod
andBluetooth.Setthesourcevolumelevelforeachmode,
dependingontherelativevolumeofeachaudiosource.
Tosetthesourcevolumelevel,pressAUDIO/MENU until
SOURCELEVELappears.Afteronesecond,thecurrent
modewillappearonthedisplay.Turnthevolume knob to
adjusttheaudiolevelofthecurrentsource(-6minimum/+6
maximum).
Note: Onlythecurrentmodewillbeavailableforadjustment.
Toadjustanothermodeofoperation,pressMODEuntilthe
desiredmodeisselected,thensetthesourcevolumelevel
forthatmode.
Escape
Audio
Bass
Treble
Balance
Fader
EQ
Subwoofer
Source Volume Level
General Operation
BASS TREBLE BALANCE FADER EQ SUBWOOFER* SOURCE LEVEL
