Dual XPR520 - Typical Wire Routing

5
Fuse Rating
Whenreplacingfuses,makesurenewfuse
is the correct type and amperage. Using an
incorrect fuse could damage the amplifier.
30ampATOx1
Main Power Connections
Connect+12V,GNDandREMwiresaccordingly.AsuitablefuseMUSTbeinstalledonthe
+12Vleadwithin18"ofthebatteryforprotectionofthevehicle’selectricalsystem.
Typical Wire Routing
Power/Ground Wire Size
Foroptimumperformance,useonlythewire
sizelistedbeloworlarger.Makesuretouse
thesamesizepowerandgroundwire.
10awg
