Caratteristiche tecniche
Technical specification
sezione / section
C 3
25
A
B
C
D
E
F
G
H
L
M
N
P
Monster 400 - 620 Aggiornamento/Update - M.Y. 2006 - edizione/edition 00
Screw retaining regulator to oil breather tank M 6x1 6
Screw retaining battery mount to silentblocks M 6x1 6
Nut retaining battery mount to cylinder head M 8x1.25 13
Control unit retaining screw M 6x1 10
Screw retaining ground cable to engine M 8x1.25 12
TPRT sensor retaining screw M 4x0.7 2
Horn mount screw M 8x1.25 15 LOCK 2
Warning horn retaining screw M 8x1.25 25 LOCK 2
Immobilizer antenna Assemble in production
line, apply Lock 11
between Antenna and
Switch cover
Nut securing temperature sensor support to
subframe
5
Relay mount retaining screw M 5x0.8 1
Front brake
Front brake caliper retaining screw M 10x1.25 43 * GREASE B
Front brake master cylinder retaining screw M 6x1 10 sequence 1 (UP) -2-1
Front/rear brake bleed nipple M 10x1 23
Brake lever pin M 8x1.25 24 LOCK 2
Rear brake
Rear brake caliper retaining screw M 8x1.25 24 * GREASE B
Brake bleeding fitting M 10x1 23
Rear brake master cylinder retaining screw M 6x1 10
Screw retaining rear brake hose clip to
swingarm
M 5x0.8 6
Rear brake fluid reservoir retaining screw M 6x1 2
Rear swingarm
Chain adjuster safety screw M 3x0.5 1.8
Chain adjuster screw M 8x1.25 8 GREASE B
Swingarm shaft screw M 10x1,5 43 * GREASE C
Aluminium swingarm shaft retaining screw M 8x1.25 18 * GREASE C
Chain sliding shoe retaining screw M 6x1 6 LOCK 1
Rear brake caliper plate retaining pin M 8x1.25 25 * LOCK 1
Handlebar
Handlebar clamp screw M 8x1.25 20 * GREASE B - sequence
1-2-1
Clutch master cylinder retaining screw M 6x1 10 sequence 1 (UP) -2-1
Clutch hose fitting M 10x1 23
Clutch bleed nipple M 6x1 4
Clutch transmission unit screw M 6x1 10
Throttle control securing screw M 6x1 10
Throttle control cover securing screw M 4x0.7 1.8
Counterweight retaining screw M 6x1 9
Part Thread (mm) Nm tolerance
±10%
Notes
