Caratteristiche tecniche
Technical specification
sezione / section
C 3
26
A
B
C
D
E
F
G
H
L
M
N
P
Monster 400 - 620 Aggiornamento/Update - M.Y. 2006 - edizione/edition 00
Rear shock absorber
Rear shock absorber upper screw M 10x1.25 42 * GREASE B
Rear shock absorber lower screw M 10x1.25 42 * GREASE B
Suspension linkage upper screw M 10x1.25 42 * GREASE B
Suspension rocker arm to frame fixing screw M 12x1.5 75 * GREASE B
Ball joints to actuating rod nut M 12x1.5 36
Front and Rear mudguards
Front mudguard retaining screw M 6x1 3 LOCK 2
Rear mudguard retaining screw M 6x1 3 LOCK 2
Number plate holder protection screw M 6x1 5.5
Splashguard to underseat retaining screw M 6x1 1.8
Number plate holder to splashguard nut M 6x1 1.9
Footpegs and Levers
Lever and gearbox pin M 8x1.25 24 LOCK 2
Gear change lever fixing screw M 6x1 10 LOCK 1
Actuating rod ball joints screw on gear change
lever
M 6x1 10
Footpeg holders to engine retaining screws M 10x1,5 36
Footpeg holders to frame retaining screws M 8x1.25 24
Heat guard to footpeg holder retaining screw M 6x1 3
Front and Rear wheel
Front wheel nut M 25x1.25 63 * GREASE B
Rear wheel shaft nut M 25x1.25 83 * GREASE B
Brake disc mounting screw M 8x1.25 24 * DRILOC 218 as OE at
BREMBO, Lock 2 for
spare parts
Rear chain sprocket nut M 10x1.25 46 * LOCK 2
Fuel Tank
Retaining screw of plastic fuel tank flange M 6x1 10
Fuel hose clamp 1.5
Fuel filler plug fixing screw M 5x0.8 6
Fuel tank hinge bracket retaining screw M 6x1 10
Fuel tank pads retaining screw M 6x1 10
Exhaust
Nut securing exhaust pipe clamp to silencers M 10x1.25 42.4 Screwdriver max.
number of revolutions
400rpm
Special screw securing exhaust manifolds to
crankcase
M 12x1.5 25 LOCK 1
Exhaust pipe to casing retaining screw M 6x1 9
1/8” gas stainless steel plugs fastener for
exhaust pipes
M 10x1.25 25
Exhaust silencer to footpeg holder retaining
screw
M 6x1 10
Exhaust pipe to head nut M 8x1.25 24
Part Thread (mm) Nm tolerance
±10%
Notes
