Monster 400 - 620 Aggiornamento/Update - M.Y. 2006 - edizione/edition 00
*
critical point for dynamic safety. Tightening torque tolerance must be: ± 5% Nm.
Note
For product specifications and symbols, refer to “Product specifications” (A_2).
Seat
Seat lock ring nut M 22x1.5 1 LOCK 3
Seat lock holder retaining screw M 5x0.8 6
Seat cover holder retaining screw M 5x0.8 3
Seat pulley screw Self-tapping LOCK 2
Screw retaining seat cover and tool box
compartment cover to seat
M 6x1 2
Seat lock retaining screw M 5x0.8 6
Oil inlet/breather
Airbox hose clip 2
Airbox stud to airbox fixing M 6x1 6
Peg to airbox stud fixing M 6x1 4
Oil breather valve hose clip M 6x1 1.2
Oil breather tank hose clip 2
Oil breather tank to frame retaining screw M 6x1 6
Fuel system, Canister
Throttle body mounting clip 2
Pressure regulator to throttle body retaining
screw
M 6x1 5
Canister mount plate nut 8
Fairing
Side body panel retaining screw M 5x0.8 0.8
Headlight fairing to bracket retaining screw M 6x1 8
Stand
Side stand plate retaining screw M 10x1,5 36 LOCK 5
Side stand sensor wire retainer screw M 6x1 10
Side stand pivot nut M 8x1.25 24
Side stand sensor retaining screw M 6x1 10
Frame
Engine to frame mounting bolt nut M 12x1.5 60 * GREASE B
Oil pipe fitting on casing M 9/16"UNF" 19
Fitting for oil delivery pipe to heads M 8x1.25 15
Part Thread (mm) Nm tolerance
±10%
