Caratteristiche tecniche
Technical specification
sezione / section
C 3
28
A
B
C
D
E
F
G
H
L
M
N
P
Monster 400 - 620 Aggiornamento/Update - M.Y. 2006 - edizione/edition 00
Engine torque settings
Part Thread (mm) Nm Min. Max. Notes
Blow-by valve M 40x1.5 40 36 44
Mesh filter duct plug M 32x1.5 42 38 46
Oil temperature sensor ring nut M 30x1.5 38 34 42 LOCK 4
Wet clutch drum nut M 25x1.5 190 180 200 GREASE B
Generator rotor nut M 24x1 270 256 284 Engine oil
Crankshaft gear fixing nut M 22x1 190 171 209 GREASE B
Oil drain plug M 22x1.5 42 38 46
Oil mesh filter M 22x1.5 42 38 46
Oil filler plug M 22x1.5 5 5 6
Steel/alum. crankshaft blanking plug M 20x1 15 13.5 16.5 THREE BOND 1375B
Gearbox drum locating screw M 16x1.5 30 27 33
Oil filter nipple M 16x1.5 42 38 46 LOCK 2 or
THREE BOND 1324
Oil cartridge filter M 16x1.5 11 10 12 Engine oil on seal
Mesh filter duct plug M 15x1 20 18 22 LOCK 5 or
THREE BOND 1375B
By-pass pump plug M 15x1 25 22 28 LOCK 5 or
THREE BOND 1375B
Ring nut for belt rollers on lay shaft M 15x1 71 64 78 GREASE A
Ring nuts for belt rollers on heads M 15x1 71 64 78 GREASE A
Generator cover inspection plug M 15x1 20 18 22 THREE BOND 1215
Nut for timing lay shaft gear M 14x1 55 50 60 GREASE A
Radiator preset plug M 14x1.5 24 21 27 LOCK 5 or
THREE BOND 1375B
Radiator preset blanking plug M 14x1.5 27 24 30 LOCK 5 or
THREE BOND 1375B
Pick-up inspection screw M 12x1 15 13 17 LOCK 2 or
THREE BOND 1324
Earth screw M 12x1 18 16 19 LOCK 2 or
THREE BOND 1324
Oil temperature sensor M 12x1.5 18 16 19 LOCK 4
Spark plugs M 12x1.25 20 18 22
Head nuts:
1st snug torque
2nd snug torque
final torque
M 10x1,5
15
25
40
23
38
27
42
Smear GREASE C on
the
underhead and thread
of the stud bolt
Con-rod bolts:
1st tight. at 50 rpm
Stopfor 2 sec. and loosen by
360°
1st snug at 30 rpm
2nd snug at 10 rpm
check angle: > 30°
Tight. at 10 rpm
M 10x1
35
20
35
70.5 66 73
Smear GREASE B on
thread
