Caratteristiche tecniche
Technical specification
sezione / section
C 3
29
A
B
C
D
E
F
G
H
L
M
N
P
Monster 400 - 620 Aggiornamento/Update - M.Y. 2006 - edizione/edition 00
Oil pump duct plug M 10x1,5 Fully home with tool
15 13 17
LOCK 5
or THREE BOND
1375B
Head stud bolts M 10x1,5 25 23 26 LOCK 2 or
THREE BOND 1324
Pressure switch M 10x1 19 17 21
Reduction bushing M 10x1 LOCK 5 or
THREE BOND 1375B
Spark plug M 10x1 15 13 17
Neutral light switch M 10x1.25 10 9 11
Clutch-side casing service plug M 10x1,5 15 13 17 LOCK 5 or
THREE BOND 1375B
Crankshaft dowels M 8x1.25 13 11 15 THREE BOND 1375B
Gearbox pawl screw M 8x1.25 25 22 28
Gear stopper screw M 8x1.25 18 16 20 LOCK 2 or
THREE BOND 1324
Intake and exhaust flange stud bolts M 8x1.25 15 13 17 LOCK 2 or
THREE BOND 1324
Intake manifold nuts M 8x1.25 23 20 26
Oil pump screws M 8x1.25 26 23 29
Casing jointing screws:
1st snug torque
final torque
M 8x1.25
19
25
17
22
21
28
GREASE B
Casing drilled screw M 8x1.25 20 18 22 GREASE B
Fixed tensioner M 8x1 20 18 22 LOCK 2 or
THREE BOND 1324
Mobile tensioner M 8x1.25 26 23 29
Ground screw M 8x1.5 13 11 15
Clutch spring screw M 6x1 6 5 7
Stator cable guide screws M 6x1 10 9 11 LOCK 2 or
THREE BOND 1324
Starter motor screws M 6x1 10 9 11 LOCK 2 or
THREE BOND 1324
Starter idle gear pin screw M 6x1 10 9 11 LOCK 2 or
THREE BOND 1324
Generator stator retaining screws M 6x1 10 9 11 LOCK 2 or
THREE BOND 1324
Flywheel / rotor screws M 6x1 13 11 15 LOCK 2 or
THREE BOND 1324
Gearbox bearing stop plate screws M 6x1 10 9 11 LOCK 2 or
THREE BOND 1324
Head service screws (aluminium) M 6x1 3 2 3 LOCK 5 or
THREE BOND 1375B
Intake manifold fuel pump fitting M 6x1 2.5 2 3 LOCK 2 or
THREE BOND 1324
Bosch pick-up retaining screws M 6x1 10 9 11
Nut securing fluid recovery tank bracket M 6x1 9 8 10
Part Thread (mm) Nm Min. Max. Notes
