Caratteristiche tecniche
Technical specification
sezione / section
C 3
30
A
B
C
D
E
F
G
H
L
M
N
P
Monster 400 - 620 Aggiornamento/Update - M.Y. 2006 - edizione/edition 00
Note
For product specifications and symbols, refer to “Product specifications” (A_2).
Battery mount lower stud bolt M 6x1 10 9 11 LOCK 2 or
THREE BOND 1324
Gearbox pawl screw M 6x1 9 8.5 9.5 LOCK 2 or
THREE BOND 1324
Inspection cover screws M 6x1 4.5 4.5 6
Rocker arm shaft cover screws M 6x1 10 9 11
Intake / exhaust valve cover screws M 6x1 10 9 11
Casing jointing screws M 6x1 9 8.5 9.5
Clutch cover screws M 6x1 9 8.5 9.5
Generator cover screws M 6x1 10 9 11
Clutch spring screws M 5x0.8 5 5 7 GREASE A
Driven belt roller flange retaining screws M 5x0.8 5 5 7
Manifold nipple M 5x0.8 3 2 3 LOCK 2 or
THREE BOND 1324
Split belt roller flange retaining screws M 5x0.8 5 5 7
Head cover plug M 5x0.8 2.5 2.5 3
Screws M 10x1,5 45 40 50
Screws M 8x1.25 25 22 28
Screws M 6x1 10 9 11
Screws M 5x1 5 5 7
Part Thread (mm) Nm Min. Max. Notes
