72
E
30) Neutral light switch
31) Oil pressure switch
32) Rear STOP light switch
33) Front STOP light switch
34) Left switch
35) Air temperature/pressure sensor
36) Instruments (instrument panel)
37) Front left-turn indicator
38) Horn
39) Headlamp
40) Front right-turn indicator
41) CPU oil temperature sensor
42) Instrument oil temperature sensor
43) Clutch switch
44) Vertical cylinder spark plug 2 (1000 only)
45) Horizontal cylinder spark plug 2 (1000 only)
Legend of the wiring diagram of electric
system/ignition
1) Right switch
2) Transponder aerial
3) Key-operated switch
4) Main relay
5) Fuse box
6) Starter motor
7) Starter solenoid
8) Battery
9) Regulator protection fuse
10) Regulator
11) Generator
12) Rear right-turn indicator
13) Tail light
14) Number plate light
15) Rear left-turn indicator
16) Tank
17) Self-diagnosis connector
18) Speed sensor
19) Horizontal cylinder coil
20) Vertical cylinder coil
21) Horizontal cylinder spark plug 1
22) Vertical cylinder spark plug 1
23) Horizontal cylinder injector
24) Vertical cylinder injector
25) Throttle position sensor
26) Timing/rpm sensor
27) Side stand switch
28) Control unit 5.9 M
29) Injection relay
