73
E
Wire color coding
B Blue
W White
V Violet
Bk Black
Y Yellow
R Red
Lb Light blue
Gr Grey
G Green
Bn Brown
O Orange
P Pink
Legend of fuse box (5)
Pos. Description Rat.
1-9 Main switch 30 A
2-10 Fuel pump, injectors, coils 20 A
3-11 Key sense 10 A
4-12 Control unit power supply 3 A
5-13 Passing 7.5 A
6-14 Parking lights, instrument panel lights,15 A
high and low beams
7-15 Stop, warning horn 10 A
8-16 Speed sensor 5 A
Note
Wiring diagram for the system is at the end of this
manual.
