Digital display (fig. 6)
8.1) Fuel level indicator .
The fuel level in the tank is indicated by full bars. When
there is only 1 full bar left on, it will start blinking while
the reserve light (4, fig. 5) will come on.
8.2) Coolant temperature indicator .
Shows engine coolant temperature. When the engine is
cold, the flashing message LO is displayed.
Engine temperature is displayed from 45 °C (113 °F) and
over. If engine maximum temperature (120 °C/248 °F) is
reached, the indicator will start blinking.
Important
Stop the engine if it reaches maximum temperature
or it may suffer severe damage.
8.3) Clock
The first figure gives hours, the second one minutes.
8.4) Clock setting button
Press it briefly to increase minutes. Keep it pressed to
speed up the process.
14
E
