Suspensions
Front
Hydraulic upside-down fork provided with outer adjuster
for rebound, compression, and preload (for inner springs
of fork legs).
Stanchion diameter: 43 mm
Travel along leg axis: 130 mm
Rear
Of the progressive type, thanks to a rocker arm
connecting frame and upper pivot point of the shock
absorber. The shock absorber - with separated reservoir -
enables the adjustment of rebound and compression
damping and spring preload. At the bottom pivot point it
is connected to a steel swingarm. The swingarm hinges
on a pivot pin passing through the engine. The whole
system gives the bike excellent stability.
Travel: 65 mm
Rear wheel travel: 148 mm
Exhaust system
Catalyzed as per Euro 2 standard.
Available colours
Ducati anniversary red 473.101
Ducati yellow 473.201
Ducati iron grey 291.600
Ducati metallic dark grey 653.6047 with
metal-color frame and red rims.
