Ducati ST4S - Page 86

86
E
Wire color coding
P Pink
G Green
W White
O Orange
Y Yellow
B Blue
Bn Brown
R Red
V Violet
Gr Grey
Lb Light blue
Bk Black
Note
The system wiring diagram is at the end of this
manual.
Legend of fuse box
Pos. Description Rat.
1-9 Main switch 30 A
2-10 Parking lights, high and low beam 20 A
3-11 Stop, horn, turn indicators 15 A
and fan
4-12 CPU power 3 A
5-13 Key sense 7.5 A
6-14 Injection 20 A
7-15 Display 3 A
8-16 Power outlet and tester power supply 20 A
