Base Connections
Figure 3-7 Press Base Rear - Grounding Stud and
J35 the Base Interface Connector
A
B
J35 - Ergonomic Base Connector
This connector is shown as B in Figure 3-7. It is used to
interface the base controls and display to the Base/Abort
connector (J6) on the thruster. See Figure 3-4 for the J6
location.
Grounding Stud
This connector is shown as A in Figure 3-7. Use this base
connector to insure proper grounding.
See RFI grounding below, and the grounding material on
Page 9.
Page 25
Dukane Manual Part No. 403-594-02
Section 3 - Installation
