Continued
Figure 4-12 Press Left Side View with Detail
Continued from Previous Page
Loosen or tighten the
mechanical stop lock with a
M5 Hex wrench.
Stroke Position
Indicator Flag
Slot
Mechanical Stop
Indicator Flag
Slot
