Dukane i220 - Page 6

Contents
Section 7 - Acoustic Stack/Fixture Setup........79
Overview.........................................81
Stack Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Changing Stack Components.........................83
Stack Assembly and Torque Values ....................85
Fixture Installation .................................87
Section 8 - Stack Maintenance ................91
Inspection of the Acoustic Stack Components ............93
Reconditioning Stack Components ....................94
Section 9 - System Maintenance...............97
Section 10 - Contacting Dukane ..............101
Section 11 - Specications ..................105
Drawings ................................... 107-109
Weights, Dimensions, Operating Environment ..........110
Compressed Air Requirements ...................... 111
AC Power Requirements ........................... 111
Models, Ultrasonic Pressure ........................112
Replacement and Repair Parts Lists ..................113
Regulatory Agency Compliance ...................... 114
Section 12 - Appendices .................... 115
Appendix A - List of Figures ......................... 117
Appendix B - List of Tables ..........................120
Index ..................................121
Continued
Continued from Previous Page
Page vi
iQ Series Ultrasonic Integrated Press System i 220 User’s Manual
Dukane Manual Part No. 403-594-02
