Duke E SERIES Installation, Operation, Parts & Maintenance Manual

Duke Manufacturing Co.
2305 N. Broadway • St. Louis, Missouri
800-735-3853 • 314-231-1130 • Fax 314-231-5074
www.dukemfg.com
3 of 22
“E” & 6/13 SERIES GAS CONVECTION OVEN
Specifications
NATURAL GAS PROPANE GAS
HEATING VALUE
1000 BTU 37.3 MJ/m
3
2550 BTU 95.0 MJ/m
3
SPECIFIC GRAVITY
0.63 0.63 1.53 1.53
GAS PRESSURE AT
MANIFOLD
3.5" W.C 0.87 kPa 10" W.C. 2.49 kPa
OVEN INPUT STANDARD DEPTH
PER BURNER
20,000 BTU/HR 5.9 kW 20,000 BTU/HR 5.9 kW
PER OVEN
40,000 BTU/HR 11.8 kW 40,000 BTU/HR 11.8 kW
OVEN INPUT DEEP DEPTH
PER BURNER
23,000 BTU/HR 6.8 kW 23,000 BTU/HR 6.8 kW
PER OVEN
46,000 BTU/HR 13.5 kW 46,000 BTU/HR 13.5 kW
BURNER ORIFICE SIZE
STANDARD DEPTH
#44 2.18mm #55 1.32mm
DEEP DEPTH
#43 2.26mm #54 1.40mm
POST IN A PROMINENT LOCATION:
Instructions to be followed in the event the user smells gas. This information shall
be obtained by consulting the local gas supplier.
FOR YOUR SAFETY:
Do not store or use gasoline or other flammable vapors or liquids in the vicinity of
this or any other appliance.
WARNING:
Improper installation, adjustment, alteration, service or maintenance can cause
property damage, injury or death. Read the installation, operating and maintenance
instructions thoroughly before installing or servicing this equipment.
