Owner's Manual for Duke Flexbake 5
TM
Proof and Bake Oven with WiFi Connectivity
DOOR ADJUSTMENT & GASKET MAINTENANCE -cont.
DOOR GASKET LEAK TEST:
The doors should be checked for leaks every three months. If
the door gasket is damaged or compressed permanently, it
should be replaced. Call Duke Manufacturing Co. at 800-735-
3853 to order a new gasket.
To check the gasket for leaks, close the door with a currency
bill between the gasket and front of the oven. Resistance
should be felt when pulling the currency bill out with the door
closed. Do this check in several places.
Figure: Gasket Check
GASKET REPLACEMENT:
Step 1 Remove the old gasket by pulling it out of the groove
in the door frame.
Step 3 Press the new gasket into the groove. Make sure it is
fully seated in the groove and at against the door frame.
Step 4 Refer to Figure: Gasket Check in this section to check
the gasket for leaks. Also, check that the new gasket is not
compressed too much, making the door hard to close. Call
Duke Service for assistance if the gasket does not seal properly.
Figure: Properly Seated Gasket
Figure: Door and Gasket
Step 2 Clean the groove with a screwdriver or other at-
bladed tool to remove any dirt or gasket pieces.
Figure: Cleaning Gasket Groove
