7
Maintenance Manual for DUKE TSC Proofer
Oven with Touch Screen Controls
PROGRAMMING CONTROLS
RECIPE EDIT PROGRAMMING
INSTRUCTIONS
1. Touch the button and then enter pin
code 5 6 7 8 and Touch the button
when prompted.
2. Touch the button for the recipe you want to
edit (i.e.
BREAD
).
NOTE: The 6 oven recipes are listed in
the top 3 rows and the 6 proofer recipes
are listed in the bottom 3 rows.
3. To edit Time, Temperature or Humidity
(Proofer Only), touch the or
button adjacent to the eld you want to
change. Touch the button to save
the changes.
NOTE: You must touch the button
in each eld to save the changes you
made.
FIGURE: Recipe Edit Selection Screen
Figure: Recipe Edit Screen
Figure: Main Tool Bar
Figure: Special Functions Screen
To access the SPECIAL FUNCTIONS, touch
button on the Main Tool Bar.
To Next Page
