Duncan EcoSeeder - EcoSeeder Seed Drill Chain Tensioner Dual Box

54
‘EcoSeeder’ Seed Drill Dual Gearbox Assembly
ITEM PART No. DESCRIPTION QTY
1 25756 Gearbox Sub-Assembly 1
2 22036 Quadrant, Speed Adjusting 2
3 25754 Lever, Front, Speed Adjusting 1
4 25755 Lever, Rear, Speed Adjusting 1
5 43366 M8 Tri-Knob Tapped Centre 2
6 47031 M8 x 30 Class 4.6 Cup Head Coach Bolt Z/P 2
7 45151 M8 Light Flat Washer Z/P 2
8 22041 Front Box Speed Indicator Label (black writing on yellow background) 1
9 22042 Rear Box Speed Indicator Label (yellow writing on black background) 1
10 44992S M8 x 20 Class 8.8 Set Screw Z/P 10
11 44993S M8 x 25 Class 8.8 Set Screw Z/P 6
12 45157 M8 HD Flat Washer Z/P 2
13 45137 M8 Nyloc Nut Z/P 16
14 25762 Gearbox Final Assembly (Includes items 1 to 13) 1
12 2
3
4
5
6
7
8
9
1011
11
11 11
111012
