58
3
2
1
‘EcoSeeder’ Seed Drill Seed Box Drive Shafts
58
ITEM PART No. DESCRIPTION QTY
1 22044 15T x 1/2”P Sprocket 20mm Bore (Front Box) 1
1 22537 25T x 1/2”P Sprocket 20mm Bore (Rear Box & Single Box) 1
2 22294 Sprocket Key (6 x6 x 25) 2
3 27886 Box Drive Shaft 2
4 43385 “Y” Bearing 4
5 43387 Bearing Housing Pressed Steel (2 Flanges = 1 Housing) 4
6 45411S M8 x 20 Class 8.8 Set Screw Z/P 8
7 45137 M8 Nyloc Nut Z/P 8
8 45180 M8 x 10 Socket Head Grubscrew 2
9 45151 M8 Light Flat Washer 8
4 4
5
57 8
Note: Single Box machine has half the quantities
of Items 2 to 8
6 9
To Next Page
